Waring WDB600X Commercial Cast-Iron Double Burner, 7.5 in and 6 in Plates, 1800W Total, 120V

The Waring WDB600X is a commercial cast-iron double burner that pairs a 7.5-inch, 1300-watt plate for fast cooking with a 6-inch, 500-watt plate for simmering and warming. With 1800 watts total on a standard 120V plug, it adds two burners to a buffet, catering setup or small kitchen without any special wiring.

Two Cast-Iron Plates, Two Jobs

Both plates have their heating elements embedded in the cast iron, which spreads heat across the plate for even cooking and quick heat-up. Splitting the wattage between a large and a small plate is a practical choice: the 1300-watt side handles eggs, sautes and boiling, while the 500-watt side gently holds sauces, gravies and soups without scorching.

Each plate has its own independent, adjustable thermostat, with POWER ON and READY indicator lights so staff can see at a glance when each burner is at temperature. The brushed stainless steel housing wipes clean, and nonslip rubber feet keep the unit steady.

Why Operators Choose It

• Cook and hold at once: 1300-watt large plate for cooking plus 500-watt small plate for simmering and warming
• Even heat: elements embedded in heavy-duty cast iron for good heat distribution and quick heat-up
• Independent control: separate adjustable thermostats with POWER ON and READY lights
• Easy cleaning: heavy-duty brushed stainless steel housing
• Standard outlet: 1800 watts total at 120V with a NEMA 5-15P plug
• Stable: nonslip rubber feet
• Made in USA: built with US and foreign parts; NSF and UL listed

Controls

Two independent adjustable thermostats, one per plate. POWER ON lights confirm each burner is energized, and READY lights signal when the plate has reached its set temperature.

Ideal For

• Buffet and omelet stations that cook and hold side by side
• Catering and off-site events
• Small kitchens, cafes and bars without a range
• Holding sauces and soups near the pass

Specifications

Electrical & Installation

• Electrical: 120V, 60 Hz, 1800 watts, 15 A with a 3 ft cord and NEMA 5-15P plug
• Dedicated circuit: at 15 A, plug into its own circuit rather than sharing with coffee makers, warmers or other heating equipment
• Placement: level, heat-tolerant surface close to the outlet given the short cord

Warranty

Waring limited one-year warranty.

Specifications per Waring data; subject to change by the manufacturer.
