Toastmaster TMGM24 24" Countertop Griddle, Manual Controls, 3/4" Steel Plate, 40,000 BTU
Sometimes the best griddle is the simplest one. The Toastmaster TMGM24 is a 24-inch countertop griddle with straightforward quarter-turn manual valves: turn the knob up for more heat, down for less. It is an easy fit for food trucks, concession stands, small cafés and any kitchen that needs a dependable flat top in a tight spot without paying for thermostats.
Two 20,000 BTU aluminized steel "U" shaped burners, one every 12 inches, deliver a total of 40,000 BTU/hr into an ultra smooth 3/4" thick polished steel plate with a 21-1/2" deep cooking surface. Each burner has its own 1/4-turn manual control valve, and a standing pilot keeps it ready to light.
What you will notice in day-to-day use
- Hands-on control. Quarter-turn manual valves respond immediately, which experienced griddle cooks often prefer for adjusting heat on the fly.
- Heat zones you can set. With a burner every 12", the 24" plate can run a hotter side and a cooler side for proteins, eggs and holding.
- A thick plate that recovers. The 3/4" polished steel plate stores plenty of heat, so it bounces back after you load cold product.
- Cleanup that keeps pace. A spatula-wide 3-1/4" front grease trough and chute drain into a 4-1/2 qt. stainless steel grease drawer, and a 4-3/8" tapered splash guard wraps around three sides.
- Protected controls. A stainless steel front panel and bull nose shield the valve knobs from bumps and spills.
Choosing your setup
Gas type: the griddle ships set up for natural gas with a universal convertible pressure regulator, and orifices for LP are included. Choose natural gas or liquid propane above to match your kitchen. Prefer a griddle that holds a set temperature? The thermostatic TMGT24 shares this body, and the TMGM series also comes in 36" and 48" widths.
Specifications
| Brand | Toastmaster |
| Model | TMGM24 |
| Type | Countertop gas griddle, manual controls |
| Burners | 2 x 20,000 BTU/hr aluminized steel "U" burners, one every 12" |
| Total input | 40,000 BTU/hr |
| Controls | 2 1/4-turn manual control valves, standing pilot |
| Griddle plate | 3/4" thick polished steel |
| Plate depth | 21-1/2" |
| Grease management | 3-1/4" front trough and chute, 4-1/2 qt. stainless grease drawer |
| Splash guard | 4-3/8" high tapered, wrap-around stainless steel |
| Gas type | Ships for natural gas; LP orifices and convertible regulator included |
| Gas connection | 3/4" NPT male, rear |
| Construction | Stainless steel front, bull nose and grease drawer; aluminized steel sides |
| Legs | 4" die-cast nickel-plated, 1-3/8" adjustment |
| Dimensions (W x D x H) | 24" x 27-13/16" x 15-1/2" |
| Net weight | 148 lb |
| Shipping weight | 158 lb |
| Certifications | cULus, UL EPH Classified (Sanitation), Made in USA |
Before it arrives
- Gas: 3/4" NPT rear connection; have a qualified installer hook it up and convert it to LP if needed.
- Ventilation: install under a commercial hood following your local code.
- Counter or stand: set it on a non-combustible counter using the 4" legs, or on a stand at least 27" tall over a combustible floor. Keep 6" from combustible surfaces at the back and sides.
- Delivery: it ships at about 158 lb in a carton roughly 32" x 29" x 19".
Warranty
1 year parts and labor from Toastmaster.
Specifications per Toastmaster data; subject to change by the manufacturer.
