Southbend PCE22S/SD-V Platinum Electric Convection Oven, Double Deck, Ventless, Standard Depth, Standard Controls, Dependent Doors, 22 kW

The Southbend PCE22S/SD-V is a Platinum electric convection oven: double deck, ventless, standard depth, standard controls, dependent doors. It draws 22 kW and is available for 208V/240V, 1 or 3-phase service, delivering even, fan-driven baking and roasting for commercial production.

Platinum Series Convection Technology

Southbend Platinum Series convection ovens use a two-speed fan to move heated air evenly through the cavity, so full loads bake, roast and reheat uniformly from rack to rack. A forced cool-down mode brings the cavity temperature down quickly between products.

Southbend's patented plug-in, plug-out control panel slides out for service access, and the coved, fastener-free porcelain interior is easy to wipe down. Glass doors with a dual door seal system open a full 180° and help hold heat in during loading.

Configuration & Features

• Standard depth design to fit most kitchen layouts.
• Double deck convection oven standing 64.8" tall for high capacity.
• Patented plug-in, plug-out control panel for easy servicing and maintenance.
• Slide-out control panel provides full view access for servicing.
• Durable stainless steel front, top, and sides for long-lasting performance.
• Dependent glass doors with full 180° opening for easy access.
• Energy-saving, high-efficiency glass windows for heat retention and visibility.
• Heat-keeping dual door seal system combined with coved, fastener-free porcelain interior for easy cleaning and improved heat retention.
• Two-speed, ½ HP fan motor ensures even cooking and airflow.
• Ventless design for flexible installation without external venting requirements.

Why Operators Choose It

• Even baking: two-speed fan for uniform heat across all racks
• Fast turnaround: forced cool-down mode between products
• Easy service: patented plug-in, plug-out slide-out control panel
• Easy cleaning: coved, fastener-free porcelain interior
• Heat retention: dual door seal system and high-efficiency glass windows
• Flexible loading: 11-position rack guides

Ideal For

• Bakeries and pastry production
• Restaurants roasting proteins and vegetables
• Schools, hospitals and institutional kitchens
• Catering and banquet production

Specifications

Installation & Utility Requirements

• Electrical: 208V 1-phase (105.8 A); 208V 3-phase (61.1 A); 240V 1-phase (91.7 A); 240V 3-phase (52.9 A), on a dedicated circuit, field wired per local code.
• Clearances from combustible construction: rear 2", left 2", right 0"
• Ventless operation: the ventless configuration is designed to operate without a Type I hood; confirm acceptance with your local authority having jurisdiction
• Professional installation by a licensed gas fitter or electrician is required by the manufacturer

Factory Options (Additional Cost)

• Ventless Design
• Independent Doors
• Stainless Steel Exterior Bottom
• Casters 4" or 6"
• Marine Edge Top
• 2" Air Insulation Panel (Stainless Steel Only)
• Stainless Steel Rear Jacket
• Down Draft Diverter for Direct Flue
• Export Crating
• Stainless Steel Dirt Tray
• Stainless Steel Solid Doors

Warranty

Southbend covers this unit with a 1 year parts and labor warranty under its current limited warranty policy. Professional installation and startup help keep coverage in force.

Specifications per Southbend data; subject to change by the manufacturer.
