Imperial IR-2-G24T-E-XB Pro Series Electric Range, 36" Wide Combination Range With Open Cabinet, 11.2 kW

The Imperial IR-2-G24T-E-XB is a 36" electric restaurant range from the Pro Series line with open cabinet. It is rated at 11.2 kW and is offered for 208V / 3-Phase, 240V / 3-Phase or 480V / 3-Phase service.

Pro Series Electric Cooking

Sealed electric elements give a flat, easy-to-clean cooktop with precise infinite controls and no open flame.

Electric heat suits kitchens without gas service, high-rises and institutions.

Why Operators Choose It

• Cooking surface: 2.6 KW round plate elements with easy-to-clean flat surface.
• Provides a solid flat surface for fast, even heating.
• Plates are 9" (229) diameter for maximum pan contact.
• Easy cleaning: The top design helps prevent spills from entering unit, making clean-up easier.
• Controls: Infinite heat controls for maximum cooking flexibility.
• Temperature control: Thick highly polished 3/4" steel plate with thermostat controls.
• 21" plate depth.

Ideal For

Restaurants, schools, hospitals and high-rise kitchens with electric service.

Specifications

Installation & Utility Requirements

Electrical service by option (field wired per local code unless noted):

Minimum clearances per Imperial: 6" sides, 8" back, 20" top, 26" front service.

Install by a qualified technician per local codes and the Imperial installation manual.

Factory Options (Additional Cost)

• 6" (152) Casters, set of 4
• 12"W x 24"D Hot Top section to replace 2 round plates, (add "-HT")
• 6" (152) stainless steel stub back, in lieu of standard backguard
• Chrome griddle top
• Extra oven rack

Warranty

1 Year Parts and Labor limited warranty from Imperial.

Download the Imperial IR-2-G24T-E-XB spec sheet (PDF)

Specifications per Imperial data; subject to change by the manufacturer.
