Imperial IR-10-E-XB Electric Pro Series Restaurant Range, 60" Wide Range (10) Round Elements (1) Standard Oven (1) Open Cabinet, 25.3-31.3 kW
The Imperial IR-10-E-XB is a 60" electric restaurant range from the Pro Series line. It is rated at 25.3-31.3 kW and is offered for 208V / 1-Phase, 208V / 3-Phase, 240V / 1-Phase, 240V / 3-Phase or 480V / 3-Phase service.
Pro Series Electric Cooking
Sealed electric elements give a flat, easy-to-clean cooktop with precise infinite controls and no open flame.
Electric heat suits kitchens without gas service, high-rises and institutions.
Why Operators Choose It
- Easy cleaning: The top design helps prevent spills from entering unit, making clean-up easier.
- Cooking surface: 2.6 KW round plates provide a solid flat surface for faster even heating.
- Temperature control: Independent, infinite heat controls for precise temperature flexibility.
- Safety: Oven controls protected from heat in an insulated side compartment.
- Stainless steel front, sides, kick plate, landing ledge, back splash and shelf from heat in an insulated side compartment.
- Griddle tops measuring 24", 36" and 48" are 1/2" (13) thick.
- Griddle tops measuring 60" and 72" are 3/4" (19) thick.
Ideal For
Restaurants, schools, hospitals and high-rise kitchens with electric service.
Specifications
| Model | IR-10-E-XB |
| Type | Electric Pro Series restaurant range, 60" wide range (10) round elements (1) standard oven (1) open cabinet |
| Electrical | 208V, 1-phase (121.6 A); 208V, 3-phase (99 A); 240V, 1-phase (105.4 A); 240V, 3-phase (90 A); 480V, 3-phase (45 A) |
| Power | 25.3 kW / 31.3 kW |
| Dimensions (W x D x H) | 60" x 30-1/2" x 56-1/2" |
| Product weight | 877 lb |
| Certifications | CE, ETL, UKCA, cETLus |
| Country of origin | United States |
| Warranty | 1 Year Parts and Labor |
Installation & Utility Requirements
Electrical service by option (field wired per local code unless noted):
| Electrical | Amps | kW |
|---|---|---|
| 208V / 1-Phase | 121.6 | 25.3 |
| 208V / 3-Phase | 99 | 31.3 |
| 240V / 1-Phase | 105.4 | 25.3 |
| 240V / 3-Phase | 90 | 31.3 |
| 480V / 3-Phase | 45 | 31.3 |
Minimum clearances per Imperial: 6" sides, 8" back, 20" top, 26" front service.
Install by a qualified technician per local codes and the Imperial installation manual.
Warranty
1 Year Parts and Labor limited warranty from Imperial.
Download the Imperial IR-10-E-XB spec sheet (PDF)
Specifications per Imperial data; subject to change by the manufacturer.
