Imperial IR-10-E-CC Electric Pro Series Restaurant Range, 60" Wide Range (10) Round Elements (2) Convection Ovens, 30.6-38.4 kW
The Imperial IR-10-E-CC is a 60" electric restaurant range from the Pro Series line. It is rated at 30.6-38.4 kW and is offered for 208V / 1-Phase, 208V / 3-Phase, 240V / 1-Phase, 240V / 3-Phase or 480V / 3-Phase service.
Pro Series Electric Cooking
Sealed electric elements give a flat, easy-to-clean cooktop with precise infinite controls and no open flame.
Electric heat suits kitchens without gas service, high-rises and institutions.
Why Operators Choose It
- Easy cleaning: The top design helps prevent spills from entering unit, making clean-up easier.
- Cooking surface: 2.6 KW round plates provide a solid flat surface for faster even heating.
- Temperature control: Independent, infinite heat controls for precise temperature flexibility.
- Safety: Oven controls protected from heat in an insulated side compartment.
- Stainless steel front, sides, kick plate, landing ledge, back splash and shelf from heat in an insulated side compartment.
- Griddle tops measuring 24", 36" and 48" are 1/2" (13) thick.
- Griddle tops measuring 60" and 72" are 3/4" (19) thick.
Ideal For
Restaurants, schools, hospitals and high-rise kitchens with electric service.
Specifications
| Model | IR-10-E-CC |
| Type | Electric Pro Series restaurant range, 60" wide range (10) round elements (2) convection ovens |
| Electrical | 208V, 1-phase (81 A); 208V, 3-phase (118 A); 240V, 1-phase (71 A); 240V, 3-phase (104 A); 480V, 3-phase (52 A) |
| Power | 30.6 kW / 38.4 kW |
| Dimensions (W x D x H) | 60" x 30-1/2" x 56-1/2" |
| Product weight | 1027 lb |
| Certifications | CE, ETL, UKCA, cETLus |
| Country of origin | United States |
| Warranty | 1 Year Parts and Labor |
Installation & Utility Requirements
Electrical service by option (field wired per local code unless noted):
| Electrical | Amps | kW |
|---|---|---|
| 208V / 1-Phase | 81 | 30.6 |
| 208V / 3-Phase | 118 | 38.4 |
| 240V / 1-Phase | 71 | 30.6 |
| 240V / 3-Phase | 104 | 38.4 |
| 480V / 3-Phase | 52 | 38.4 |
Minimum clearances per Imperial: 6" sides, 8" back, 20" top, 26" front service.
Install by a qualified technician per local codes and the Imperial installation manual.
Warranty
1 Year Parts and Labor limited warranty from Imperial.
Download the Imperial IR-10-E-CC spec sheet (PDF)
Specifications per Imperial data; subject to change by the manufacturer.
