Groen DEE/4T-40CTA/3 40 Gallon Steam Jacketed Kettle - 2/3 Jacket, Twin Shaft Agitator

The DEE/4T-40CTA/3 is a floor machine of 40 gallons, with the agitator drive carried over the vessel. Elements heat water in a sealed reservoir and the jacket takes its steam from there, which keeps the whole heat path inside the machine. It takes a standing job off the range line.

Steam occupies the lower two thirds of the jacket space, spreading the load over a curved wall instead of a flat plate. The sheet gives 50 PSI as the maximum working pressure. Worm gearing under the crank carries the weight, so the vessel tips at the speed the handle is turned. The TA/3 head carries two agitator shafts, which share the work of turning a mass a single paddle would drag through.

The interior is 316 stainless, the exterior 304. Type 316 stainless lines the vessel, and that grade is what carries an acidic menu year after year. Controls come as either the Classic or the Advanced package. The listings are UL, NSF and ASME. Cleaning is a wash and a rinse rather than a strip-down.

Features

• Two mixing shafts — continuous movement through a heavy batch.
• Rated 50 PSI maximum — the jacket limit is published.
• Two control tiers — Advanced adds timed, repeatable batches.
• Holds 40 Gallons — commissary batches without splitting the cook.
• Hand-crank tilt — one person empties a full kettle.
• ASME stamped jacket — the paperwork a jurisdiction wants.
• Heated electrically — steady output on one circuit.
• Offered for 208 V or 240 V, single or three phase — select the electrical option above.
• Jacket covers two thirds — gentle on cream soups.
• 316 stainless construction — better chloride resistance than 304.
