Groen DEE/4T-40ATA/3 40 Gallon Steam Jacketed Kettle - 2/3 Jacket, Twin Shaft Agitator

Electric elements raise the steam for the DEE/4T-40ATA/3, a 40-gallon kettle that needs a circuit and nothing else. It stands on legs over an enclosed base, with the agitator drive carried overhead. It is bought where the batch is made in quantity rather than to order.

Steam occupies the lower two thirds of the jacket space, spreading the load over a curved wall instead of a flat plate. The jacket is stamped for 50 PSI maximum working pressure. The crank drives a worm gear, which means a full vessel cannot run away mid-pour and the rate is whatever the cook chooses. Mixing is by twin shaft head, which puts a blade on each side of the vessel rather than one down the middle.

The cooking interior is 316 stainless with a 304 jacket around it, as the sheet specifies. Lining is 316 stainless, the grade to have where tomato and salt are routine. Control choice is between the Classic and Advanced packages. Groen lists the DEE/4T-40ATA/3 to UL, NSF and ASME. Cleaning is a wash and a rinse rather than a strip-down.

Features

• Two mixing shafts — continuous movement through a heavy batch.
• Rated 50 PSI maximum — the jacket limit is published.
• Offered for 208 V or 240 V, single or three phase — select the electrical option above.
• 40 Gallons — the standard size for institutional feeding.
• Electrically heated — nothing to light, nothing to vent.
• Floor standing on stainless legs — fixed in the line.
• 2/3 steam jacket — heat around the load, dairy will not scorch.
• NSF listing — the cleanability code jurisdictions adopt.
• 316 stainless construction — better chloride resistance than 304.
• Two control tiers — Advanced adds timed, repeatable batches.
