Blodgett MARK V-100 Single Full-Size Electric Convection Oven - 11 kW, 220-240V/3ph, Stacking Section

The additional section is the upper half of a Mark V-100 stack: it sets onto a section already in place rather than standing on its own legs, and it adds a second 11 kW compartment without taking a second floor position. The cavity matches the base at 29 inches wide, 20 high and 24-1/4 deep, five 18 by 26 inch pans across eleven rack positions, and it keeps its own control, so the two decks can be run at different temperatures.

• Adds a second compartment above an installed Mark V-100 without widening the line.
• 11 kW per section from a three-element heater bank, driven by a 1/2 H.P. fan motor that runs at 1120 or 1710 RPM.
• Five 18 by 26 inch sheet pans over eleven rack positions, at a minimum spacing of 1-5/8 inches.
• Its own controls per section: LED readout, Cook & Hold and Pulse Plus, 200°F to 500°F.
• Stacked pairs sit on 6 inch adjustable stainless legs rather than the 25 inch legs a standalone single uses.
• Three years parts, two years labor, and five years limited on the doors.

Specifications

• Model: MARK V-100
• Configuration: Single section, additional section
• Fuel: Electric
• Electrical supply: 220-240V / 3-phase / 11 kW
• Interior cavity: 29" (737mm) W x 20" (508mm) H x 24-1/4" (616mm) D
• Capacity: Accepts five 18" x 26" standard full-size baking pans per compartment
• Racks: Five chrome-plated removable racks
• Rack spacing: Minimum of 1-5/8" (41mm)
• Temperature range: 200°F (93°C) to 500°F (260°C)
• Controls: SSD solid state digital control with LED display, Cook & Hold and Pulse Plus (standard); SSI-M solid state infinite with manual timer (optional)
• Doors: Dual pane thermal glass window encased in stainless steel door frame; triple-mounted pressure lock door design with turnbuckle assembly
• Weight: 490 lbs. (222 kg)
• Certifications: ENERGY STAR qualified
• Warranty: Three year parts and two year labor warranty. Five year limited oven door warranty.

Questions & answers

What is the Blodgett MARK V-100 Single Full-Size Electric Convection Oven?
The MARK V-100 Single Full-Size Electric Convection Oven is electric convection oven, Accepts five 18" x 26" standard full-size baking pans per compartment, supplied at 220-240V / 3-phase / 11 kW. It operates from 200°F (93°C) to 500°F (260°C).

How big is the cavity on the MARK V-100 Single Full-Size Electric Convection Oven?
The baking compartment measures 29" (737mm) W x 20" (508mm) H x 24-1/4" (616mm) D.

What power supply does the MARK V-100 Single Full-Size Electric Convection Oven need?
This listing is the 220-240V / 3-phase / 11 kW build.
