Blodgett HV-100E Single Full-Size Electric Convection Oven - 15 kW, 240V/3ph, Stacking Section

Added above an oven already installed, this electric HydroVection section brings continuous humidity to a second cavity inside the same 38.1" wide footprint. Six tubular elements draw 15 kW per section and a four-speed auto-reversing fan moves the air, while incremental humidity control and the Hydroburst shot cover roasting, poaching and gratinating alongside dry baking. The 29" by 23.43" cavity holds five full-size 18" x 26" pans across ten rack positions, at 450 lbs per section.

• Incremental humidity control holds moisture in the cavity through the bake, and Hydroburst releases a shot of 100% humidity when a crust needs it.
• The split door opens both halves at once on a catch-latch system, so a cook can load the upper section one-handed.
• A dual pane tempered window with Low-E inner glass keeps the outer surface cool enough to pass in a tight aisle.
• Five stainless racks and ten positions take full-size sheet pans or ten 12" x 20" steam table pans per section.
• A 4" removable fillet probe drives cook and hold, and recipes move on and off the control over USB.
• ENERGY STAR qualified, with one year of parts and one year of labor coverage.

Specifications

• Model: HV-100E
• Configuration: Single section, additional section
• Fuel: Electric
• Electrical supply: 240V / 3-phase / 15 kW
• Interior cavity: 29" (737mm) W x 20" (508mm) H x 23.43" (595mm) D
• Capacity: Accepts five 18" x 26" standard full-size baking pans
• Racks: Five stainless steel racks
• Temperature range: 140-500°F
• Controls: Standard control with function selection for hot air, humidity and cool down; stores 100 recipes; USB connection; core probe cook and hold
• Doors: Black glass doors with one piece curved handle; simultaneous split door operation with catch-latch system
• Water connection: 3/4" NPT garden hose - cold water only; 30 (min) - 50 (max) PSI; consumption 2.5 - 4.0 GPH based on cooking mode
• Weight: 450 lbs. (204 kg) per section
• Certifications: ENERGY STAR qualified
• Warranty: 1 year parts and 1 year labor warranty.

Questions & answers

What is the Blodgett HV-100E Single Full-Size Electric Convection Oven?
The HV-100E Single Full-Size Electric Convection Oven is electric convection oven, Accepts five 18" x 26" standard full-size baking pans, supplied at 240V / 3-phase / 15 kW. It operates from 140-500°F.

How big is the cavity on the HV-100E Single Full-Size Electric Convection Oven?
The baking compartment measures 29" (737mm) W x 20" (508mm) H x 23.43" (595mm) D.

What power supply does the HV-100E Single Full-Size Electric Convection Oven need?
This listing is the 240V / 3-phase / 15 kW build.
