Blodgett DFG-50 Single Half-Size Gas Convection Oven - 27,500 BTU, Liquid Propane, Stacking Section

An additional half-size section stacks onto a DFG-50 already in service rather than standing on its own. It brings a second propane cavity, 15-3/8 inches wide by 21 deep, with nine rack positions and five removable chrome plated racks, plus its own manual control: thermostat on one dial, timer on another, across a 200 F to 500 F range. For a kitchen that has outgrown one half-size oven but has no floor to spare, this is the way up rather than out.

• Sets onto an installed DFG-50, so a second cavity costs no extra floor space.
• Separate dials for thermostat and timer on the standard SSI-M control, with SSD digital or SimpleTouch touchscreen offered instead.
• Nine rack positions and five removable chrome plated racks, 1-5/8 inches apart at the minimum.
• Porcelainized on both interior faces, which keeps rust from starting under the finish.
• Runs on propane at 11.0 to 13.0 inches W.C. inlet pressure, behind a 1/3 H.P. single speed fan motor.

Specifications

• Model: DFG-50
• Series: Premium / Dual Flow (DFG)
• Configuration: Single section, additional section
• Fuel: Liquid Propane
• Interior cavity: 15-3/8" (390mm) W x 20" (508mm) H x 21" (533mm) D
• Capacity: Accepts five 13" x 18" standard half-size pans
• Rack spacing: minimum of 1-5/8" (41mm) spacing
• Temperature range: 200 F (93 C) to 500 F (260 C)
• Controls: Standard: manual with solid state thermostat (SSI-M); Optional: Solid State digital with LED display, cook and hold, PulsePlus(R)
• Doors: Solid stainless steel, or dual pane thermal glass window encased in stainless steel door frame; right-hand hinge
• Gas connection: 3/4" NPT
• Weight: 335 lbs
• Warranty: Three year oven parts and two year labor warranty; Five year limited oven door warranty

Questions & answers

What is the Blodgett DFG-50 Single Half-Size Gas Convection Oven?
The DFG-50 Single Half-Size Gas Convection Oven is gas convection oven, Accepts five 13" x 18" standard half-size pans. It operates from 200 F (93 C) to 500 F (260 C).

How big is the cavity on the DFG-50 Single Half-Size Gas Convection Oven?
The baking compartment measures 15-3/8" (390mm) W x 20" (508mm) H x 21" (533mm) D.

What are the DFG-50 Single Half-Size Gas Convection Oven utility requirements?
It runs on liquid propane: gas connection 3/4" NPT.
