Blodgett DFG-200-ES Single Full-Size Gas Convection Oven - 50,000 BTU, Natural Gas, Stacking Section

This is the second deck, not the first. An additional section ships to stack onto a DFG-200-ES already on the line, with its own natural gas supply at 50,000 BTU/hr and its own controls. What it adds is five 18 by 26 inch pans per load across eleven rack positions inside a bakery depth compartment, all of it ENERGY STAR qualified. Once stacked, the pair rides on 6 inch legs and needs no clearance to the walls beside it.

• Adds a full ENERGY STAR section above an existing oven rather than taking a second floor position.
• Its own gas connection at 7.0 to 10.5 inches W.C. inlet and 3.5 inches at the manifold, on 3/4 inch NPT.
• Independent controls and thermostat, 200 F to 500 F, so the upper cavity need not match the lower one.
• Five chrome plated racks over eleven positions, 1-5/8 inches apart at the tightest.
• Slide out modular control panel, which keeps service quick on the upper deck of a stack.

Specifications

• Model: DFG-200-ES
• Series: Premium / Dual Flow (DFG)
• Configuration: Single section, additional section, bakery depth
• Fuel: Natural Gas
• Heat input: 50,000 BTU/hr (14.6 Kw) per oven section
• Capacity: Five 18" x 26" pans per section
• Racks: Five chrome-plated racks, eleven rack positions
• Rack spacing: minimum of 1-5/8" (41mm) spacing
• Temperature range: 200 F (93 C) to 500 F (260 C)
• Doors: Dual pane thermal glass windows, or solid stainless steel
• Gas connection: 3/4" NPT
• Weight: 617 lbs
• Certifications: ENERGY STAR qualified
• Warranty: Three year parts and two year labor warranty; Five year limited oven door warranty

Questions & answers

What is the Blodgett DFG-200-ES Single Full-Size Gas Convection Oven?
The DFG-200-ES Single Full-Size Gas Convection Oven is gas convection oven, Five 18" x 26" pans per section, rated at 50,000 BTU/hr. It operates from 200 F (93 C) to 500 F (260 C).

What are the DFG-200-ES Single Full-Size Gas Convection Oven utility requirements?
It runs on natural gas: 50,000 BTU/hr (14.6 Kw) per oven section, gas connection 3/4" NPT.

What warranty comes with the DFG-200-ES Single Full-Size Gas Convection Oven?
Blodgett covers it with three year parts and two year labor warranty; Five year limited oven door warranty.
