Features:
- Stainless steel exterior and interior
- Welded stainless steel tank
- Heavy duty burners with a stnding flame and standby pilots
- High quality thermostat maintains select temperature automatically between 200F-400F
- Oil cooling zone in the bottom of the tank captures food particles and extends oil life
- Safety valve with an automatic voltage stabilizing function
- Self-reset high temperature limiting device
- Two(2) nickel plated baskets with coated handles standard
- Wire mesh crumb screen and basket hanger standard
- Available in Natural & Propane gas
- 3/4 NPT rear gas connection and regulator
- Four(4) casters standard
Model | Burners and Control Method |
Gas Type | Intake-tube Pressure (in. W.C.) |
Per B.T.U./h |
Total B.T.U./h |
Basket Dimensions |
Exterior Dimension |
Nozzle No.# |
Regulator | Net Weight lbs |
Gross Weight lbs |
---|---|---|---|---|---|---|---|---|---|---|---|
ATFS-50 | 4 Burners Independent Manual Control |
NG LP |
4 10 |
34,000 30,000 |
136,000 120,000 |
13 3/106 1/2 5 9/10 | 15 3/530 1/1044 2/5 | NG36 LP52 |
4" w.c. 10" w.c. |
143 | 171 |
