American Range Majestic ME-1 Single Deck Electric Convection Oven, Bakery Depth, 12 kW

The American Range Majestic ME-1 is a single-deck, full-size electric convection oven with a bakery-depth cavity. It is rated at 12 kW and holds five chrome racks on a 12-position rack guide. It is built in the USA and operates on 208V or 240V, 1-phase or 3-phase service.

Convection Baking & Roasting

A 1/2 HP two-speed blower circulates heated air through the porcelainized oven cavity: low speed for delicate baked goods and high speed for roasting and browning. The thermostat adjusts from 200°F to 500°F, and a cool-down switch brings the cavity temperature down quickly between products.

Each rack takes a full 18" x 26" sheet pan placed side to side, or two 12" x 20" hotel pans. The 50/50 dependent doors swing 135° for easy one-handed loading and come with glass windows (GG) as standard or solid stainless doors (SS) as an option.

Why Operators Choose It

• Full capacity: Five chrome racks and 12 rack positions per deck.
• Two-speed fan: 1/2 HP blower with low and high speeds.
• Simple controls: Thermostat 200°F to 500°F, 1-hour timer and cool-down switch.
• Easy loading: 50/50 dependent doors with a 135° swing.
• Easy cleaning: Porcelainized oven interior.
• Durable: All stainless steel front, sides and top; made in the USA.

Controls

Thermostat from 200°F to 500°F, 1-hour timer, two-speed fan switch and cool-down switch.

Ideal For

Bakeries, restaurants, cafés, schools, hospitals and catering kitchens baking sheet-pan products or roasting in volume.

Specifications

Installation & Utility Requirements

Hard-wire each deck to a 208V or 240V circuit: 50 A on single-phase or 30 A on three-phase service, 60 Hz. Specify voltage and phase when ordering; a cord and plug are not included.

For use only on non-combustible floors, on legs or casters (or with a 2-inch overhang when curb mounted). Clearance from non-combustible walls is 0 inches; next to combustible walls keep more than 12 inches at the sides and 4 inches at the rear. Provide ventilation per NFPA 96 and local codes.

What's Included

• Majestic ME-1 electric convection oven
• 5 chrome racks
• 6" legs or casters

Factory Options & Accessories (Additional Cost)

• Solid stainless steel doors (SS)
• Cooling/storage racks
• Seismic feet
• 208/240V motor and/or transformer

Warranty

Two-year limited parts and labor warranty from American Range.

Specifications per American Range data; subject to change by the manufacturer.
