American Range Majestic M-1 Single Deck Gas Convection Oven, Bakery Depth, 75,000 BTU

The American Range Majestic M-1 is a single-deck, full-size gas convection oven with a bakery-depth cavity, rated at 75,000 BTU/hr. Each deck holds five chrome racks on a 12-position rack guide. It runs on natural gas or liquid propane; select the gas type above.

Convection Baking & Roasting

A 1/2 HP two-speed fan circulates heated air through the porcelainized cavity: low speed for delicate baked goods and high speed for roasting. The thermostat adjusts from 200°F to 500°F, with a 1-hour timer and a cool-down mode.

Each rack takes a full 18" x 26" sheet pan or two 12" x 20" hotel pans. Glass dependent doors open 135° for easy one-handed loading; solid doors are optional.

Why Operators Choose It

• Full capacity: Five chrome racks, 12 positions per deck.
• Two-speed fan: 1/2 HP fan, low and high speeds.
• Simple controls: Thermostat 200°F to 500°F, 1-hour timer, cool-down mode.
• Easy loading: Dependent doors with 135° swing.
• Easy cleaning: Porcelainized oven interior.
• Made in the USA: Stainless steel front, sides and top.

Controls

Thermostat from 200°F to 500°F, 1-hour timer, two-speed fan switch and cool-down mode.

Ideal For

Bakeries, restaurants, schools, hospitals and catering kitchens baking and roasting in volume.

Specifications

Installation & Utility Requirements

Connect to the gas supply with the inlet size shown above. Manifold pressure is 5.0" W.C. on natural gas and 10.0" W.C. on propane (the countertop griddles use 4.0" W.C. on natural gas through the supplied regulator, which must be installed). Specify the gas type, and the altitude if above 2,000 feet; have a qualified technician make the connection and check pressures at start-up.

For use only on non-combustible floors, on legs or casters. Clearance from non-combustible walls is 0 inches; next to combustible walls keep more than 12 inches at the sides and 4 inches at the rear. A 120V outlet is needed for the fan. Install under a ventilation hood per NFPA 96 and local codes. If the unit sits on a stand with casters, use a flexible gas connector with a restraining device.

What's Included

• Majestic M-1 gas convection oven, set up for the gas type ordered
• 5 chrome racks
• 6" legs or casters

Factory Options & Accessories (Additional Cost)

• Solid stainless steel doors
• Cooling/storage racks
• Seismic feet
• Direct vent adapter

Warranty

Two-year limited parts and labor warranty from American Range.

Specifications per American Range data; subject to change by the manufacturer.
