American Range ARSHP-24-4 24" Countertop Gas Hot Plate, 4 Burners, 128,000 BTU
The American Range ARSHP-24-4 is a 24-inch countertop hot plate with 4 two-piece, lift-off 32,000 BTU/hr open burners (128,000 BTU/hr total) under heavy-duty 12" x 12" cast-iron grates. It runs on natural gas or liquid propane; select the gas type above.
Heavy-Duty Open Burners
Each burner has its own manual valve and stainless steel pilot for instant ignition. The cast-iron grates lift out for cleaning, and a full-width stainless steel crumb tray slides out from the front.
Why Operators Choose It
- Power: 4 x 32,000 BTU/hr lift-off burners.
- Durable grates: Removable 12" x 12" cast-iron grates.
- Instant ignition: Stainless steel pilot on each burner.
- Easy cleaning: Full-width removable crumb tray.
- Fits any line: 4" adjustable inset legs and 4" back riser.
Controls
Manual gas valve and standing pilot for each burner.
Ideal For
Restaurants, caterers and ethnic kitchens that need extra burner capacity on a counter or stand.
Specifications
| Model | ARSHP-24-4 |
| Type | Countertop gas hot plate |
| Width | 24" |
| Burners | 4 x 32,000 BTU/hr |
| Total input | 128,000 BTU/hr |
| Gas type | Natural gas or liquid propane (select option) |
| Back riser | 4" |
| Legs | 4" adjustable inset legs |
| Certifications | cETLus, ETL Sanitation |
| Warranty | 2-year limited parts & labor |
Installation & Utility Requirements
Connect to the gas supply with the inlet size shown above. Manifold pressure is 5.0" W.C. on natural gas and 10.0" W.C. on propane (the countertop griddles use 4.0" W.C. on natural gas through the supplied regulator, which must be installed). Specify the gas type, and the altitude if above 2,000 feet; have a qualified technician make the connection and check pressures at start-up.
For use only on non-combustible floors and counters, on legs or casters (or with a 2-inch overhang when curb mounted). Clearance from non-combustible walls is 0 inches; next to combustible walls keep at least 12 inches at the sides and 4 inches at the rear. Install under a ventilation hood per NFPA 96 and local codes. If the unit sits on a stand with casters, use a flexible gas connector with a restraining device.
What's Included
- American Range ARSHP-24-4 hot plate, set up for the gas type ordered
- 4" adjustable legs
Factory Options & Accessories (Additional Cost)
- Stainless steel stand
- Casters for stand
Warranty
Two-year limited parts and labor warranty from American Range.
Specifications per American Range data; subject to change by the manufacturer.
