American Range ARMG-24 24" Countertop Gas Griddle, Manual Controls, 1" Steel Plate, 60,000 BTU

The American Range ARMG-24 is a 24-inch countertop gas griddle with a 1-inch thick steel plate and a 21-inch cooking depth. 2 burners rated at 30,000 BTU/hr each (one every 12 inches, 60,000 BTU/hr total) are set with manual control valves. It runs on natural gas or liquid propane; select the gas type above.

Even Heat Across the Plate

A 30,000 BTU/hr burner under every 12 inches of plate gives each section its own heat source, so the griddle can run different temperatures side by side. The 1-inch steel plate stores heat for fast recovery when cold product goes down.

Manual valves give the cook direct, immediate control of flame height in each section, with standing pilots for instant ignition.

Why Operators Choose It

• Thick plate: 1-inch steel griddle plate with a 21-inch cooking depth.
• Zoned heat: 2 burners, one every 12 inches, 30,000 BTU/hr each.
• Controls: Manual control valve per burner.
• Easy cleanup: Splash guard, stainless steel grease trough and removable grease drawer.
• Fits any line: 4-inch adjustable inset legs to sit on a marine-edge equipment stand; stainless steel front, sides and landing ledge.
• Made in the USA: Built by American Range in California.

Controls

Manual gas valve for each burner, with standing pilots.

Ideal For

Restaurants, diners, cafés, food trucks and concession stands that need a dependable countertop griddle.

Specifications

Installation & Utility Requirements

Connect to the gas supply with the inlet size shown above. Manifold pressure is 5.0" W.C. on natural gas and 10.0" W.C. on propane (the countertop griddles use 4.0" W.C. on natural gas through the supplied regulator, which must be installed). Specify the gas type, and the altitude if above 2,000 feet; have a qualified technician make the connection and check pressures at start-up.

Keep 6 inches at the sides and rear from combustible construction (0 inches from non-combustible walls) and 4 inches underneath; use the supplied 4-inch legs. Install under a ventilation hood per NFPA 96 and local codes. If the unit sits on a stand with casters, use a flexible gas connector with a restraining device.

What's Included

• American Range ARMG-24 griddle, set up for the gas type ordered
• Gas pressure regulator
• 4" adjustable legs

Factory Options & Accessories (Additional Cost)

• Stainless steel equipment stand (legs or casters)
• Common plate shelf / condiment rail

Warranty

Two-year limited parts and labor warranty from American Range.

Specifications per American Range data; subject to change by the manufacturer.
