American Range ARKB-72 72" Countertop Gas Kebob Broiler, 12 Burners, 360,000 BTU

The American Range ARKB-72 is a 72-inch countertop kebob broiler with 12 individually controlled stainless steel burners, one every 6 inches at 30,000 BTU/hr (360,000 BTU/hr total), under heavy-duty angled radiants. It runs on natural gas or liquid propane; select the gas type above.

Built for Skewers

A heavy-gauge stainless steel frame is spaced to support shish skewers directly over the heat, with four skewers per foot; one set of skewers comes standard. Angled radiants spread heat evenly and control flare-ups while still giving char-broiled flavor, and they remove for cleaning along with the full-width grease tray.

Why Operators Choose It

• High output: 12 x 30,000 BTU/hr burners, individually controlled.
• Even heat: Angled, removable radiants.
• Skewer frame: Supports four skewers per foot; skewers included.
• Easy cleaning: Full-width removable grease tray.
• Made in the USA: Stainless steel construction.

Controls

Individual manual valve for each burner.

Ideal For

Mediterranean, Middle Eastern, Persian and Indian restaurants grilling kebobs and skewers in volume.

Specifications

Installation & Utility Requirements

Connect to the gas supply with the inlet size shown above. Manifold pressure is 5.0" W.C. on natural gas and 10.0" W.C. on propane (the countertop griddles use 4.0" W.C. on natural gas through the supplied regulator, which must be installed). Specify the gas type, and the altitude if above 2,000 feet; have a qualified technician make the connection and check pressures at start-up.

For use only on non-combustible floors and counters, on legs or casters (or with a 2-inch overhang when curb mounted). Clearance from non-combustible walls is 0 inches; next to combustible walls keep at least 12 inches at the sides and 4 inches at the rear. Radiant broilers are for non-combustible locations only. Install under a ventilation hood per NFPA 96 and local codes. If the unit sits on a stand with casters, use a flexible gas connector with a restraining device.

What's Included

• American Range ARKB-72 kebob broiler, set up for the gas type ordered
• One set of skewers
• 4" adjustable legs

Factory Options & Accessories (Additional Cost)

• Equipment stand

Warranty

Two-year limited parts and labor warranty from American Range.

Specifications per American Range data; subject to change by the manufacturer.
